Product Range

Ria(Rockwell innovative automatic tester)

Ria(Rockwell innovative automatic tester)

One touch, easy hardness measurement

One touch, easy hardness measurementAll testing cycle(Pre.test force - Test force - Release force) can be easily done only by touching the start button of a touch panel.

Closed-loop test force contron(with load cell)

Test force is controllable with high precision from the output of a load cell. Test force is controllable with high precision from the output of a load cell. Feedback control controls the vibration from the outside. Feedback control controls the vibration from the outside.

Test methods

Full-scale Rockwell hardness testing and Brinell hardness testing(only load) can be done.

Rockwell

HR15N HR15W HR15Y HRG HRP
HR30N HR30W HR30Y HRB HRM
HR45N HR45W HR45Y HRF HRL
HR15T HR15X HRC HRK HRV
HR30T HR30X HRD HRE HRS
HR45T HR45X HRA HRH HRR

Brinell

61.29N 98.07N 153.2N 245.2N 294.2N
306.5N 612.9N 980.7N 1226N 1839N

Variable test force

Variable test forceThe variable test force function can change pre. test force at a 100gf step from 29.42N to 98.07N(3kgf to 10kgf), and it can change test force power at a 0.9807N(100gf) step from 147.1N to 1840N(15kgf to 187.5kgf).

Top surface based measurement

Top surface based can be measured compared with the conventional bottom surface based, without being subject to the influence of a specimen bottom.

Top surface based measurement

LED indicator

LED indicatorLED indicator is displayed so tha LED may flow during operation. Operation of a testing machine can check easily.

Light weight & Compact

Light weight & CompactThe optimal design realized the light weight and the compact. Operation of the testing machine which was difficult until now can also be performed easily.

download to catalog estimate

Please understand, The details and quantity of specifications described in this table or in brochures maybe changed without notice following changes due to improvements.
